Used for 4”4.5”5”7" and 9" angle grinder, 100/115/125/150/180&230mm diameter products are suit to Europe, South-America, Middle-east and etc.
Used for 4”4.5”5”7" and 9" angle grinder, 100/115/125/150/180&230mm diameter products are suit to Europe, South-America, Middle-east and etc.
3.2/3.0/2.5mm thickness widely used for various cutting application. Increase side strength to Ensure safer application.
Has perfect abrasive performance and extra durability on application of steel, obvious advantage among the competition of various brands.
Considering Ergonomics, 3.0mm thickness cutting disc reduces the shake and keep superior balance.
Superior Durability
Ultrahigh cutting speed
High break-resistance
Super high toughness
Low heat generation
Comfortable cutting experience
Economic
No block
Material of Thin-walled tube
Various section bars
Various Plates
Rebar
Round steel
Trapezoidal profile
Threaded rod
Cable trough
Corrugated plate
Steel plate with plastic coating
Painted steel plate
Angle iron
Angle steel
Tool steels
Construction steels
Spring steels
Cast steels
High strength structural steel
Mild steels
Item number | Dimension | Dimension | Speed(RPM) | Speed(m/s) | QTY/BOX | QTY/CTN |
41A0751010N2B | 75×1.0×10 | 3×1/25×3/8 | 20100 | 80 | 100 | 600 |
41A0751610N2B | 75×1.6×10 | 3×1/16×3/8 | 20100 | 80 | 100 | 600 |
41A1001016N2B | 100×1.0×16 | 4×1/25×5/8 | 15200 | 80 | 100 | 600 |
41A1001216N2B | 100×1.2×16 | 4×3/64×5/8 | 15200 | 80 | 100 | 600 |
41A1001616N2B | 100×1.6×16 | 4×1/16×5/8 | 15200 | 80 | 100 | 600 |
41A1002016N2B | 100×2.0×10 | 4×5/64×3/8 | 15200 | 80 | 100 | 400 |
41A1002516N2B | 100×2.5×16 | 4×3/32×5/8 | 15200 | 80 | 50 | 400 |
41A1003016N2B | 100×3.0×16 | 4×1/8×5/8 | 15200 | 80 | 50 | 200 |
41A1051016N2B | 105×1.0×16 | 4×1/25×5/8 | 15200 | 80 | 100 | 600 |
41A1051216N2B | 105×1.2×16 | 4×3/64×5/8 | 15200 | 80 | 50/100 | 500/600 |
41A1051616N2B | 105×1.6×16 | 4×1/16×5/8 | 15200 | 80 | 100 | 600 |
41A1150822N2B | 115×0.8×22.2 | 41/2×1/32×7/8 | 13300 | 80 | 100 | 400 |
41A1151022N2B | 115×1.0×22.2 | 41/2×1/25×7/8 | 13300 | 80 | 100 | 400 |
41A1151222N2B | 115×1.2×22.2 | 41/2×3/64×7/8 | 13300 | 80 | 100 | 400 |
41A1151622N2B | 115×1.6×22.2 | 4 1/2×1/16×7/8 | 13300 | 80 | 100 | 400 |
41A1152022N2B | 115×2.0×22.2 | 4 1/2×5/64×7/8 | 13300 | 80 | 100 | 400 |
41A1152522N2B | 115×2.5×22.2 | 4 1/2×3/32×7/8 | 13300 | 80 | 25 | 400 |
41A1153022N2B | 115×3.0×22.2 | 4 1/2×1/8×7/8 | 13300 | 80 | 25 | 200 |
41A1250822N2B | 125×0.8×22.2 | 41/2×1/32×7/8 | 12250 | 80 | 100 | 400 |
41A1251022N2B | 125×1.0×22.2 | 5×1/25×7/8 | 12250 | 80 | 100 | 400 |
41A1251222N2B | 125×1.2×22.2 | 5×3/64×7/8 | 12250 | 80 | 100 | 400 |
41A1251622N2B | 125×1.6×22.2 | 5×1/16×7/8 | 12250 | 80 | 100 | 400 |
41A1252022N2B | 125×2.0×22.2 | 5×1/64×7/8 | 12200 | 80 | 100 | 400 |
41A1252522N2B | 125×2.5×22.2 | 5×3/32×7/8 | 12200 | 80 | 25 | 400 |
41A1253022N2B | 125×3.0×22.2 | 5×1/8×7/8 | 12200 | 80 | 25 | 200 |
41A1501622N2B | 150×1.6×22.2 | 6×1/16×7/8 | 10200 | 80 | 50 | 200 |
41A1502022N2B | 150×2.0×22.2 | 6×5/64×7/8 | 10200 | 80 | 50 | 400 |
41A1502522N2B | 150×2.5×22.2 | 6×3/32×7/8 | 10200 | 80 | 25 | 200 |
41A1503022N2B | 150×3.0×22.2 | 6×1/8×7/8 | 10200 | 80 | 25 | 200 |
41A1801622N2B | 180×1.6×22.2 | 7×1/16×7/8 | 8600 | 80 | 50 | 200 |
41A1802022N2B | 180×2.0×22.2 | 7×1/12×7/8 | 8600 | 80 | 50 | 200 |
41A1802522N2B | 180×2.5×22.2 | 7×3/32×7/8 | 8600 | 80 | 25 | 100 |
41A1803022N2B | 180×3.0×22.2 | 7×1/8×7/8 | 8600 | 80 | 25 | 100 |
41A2301622N2B | 230×1.6×22.2 | 9×1/16×7/8 | 6600 | 80 | 50 | 100 |
41A2301822N2B | 230×1.8×22.2 | 9×1/14×7/8 | 6600 | 80 | 50 | 100 |
41A2302022N2B | 230×2.0×22.2 | 9×5/64×7/8 | 6600 | 80 | 50 | 100 |
41A2302522N2B | 230×2.5×22.2 | 9×3/32×7/8 | 6600 | 80 | 25 | 50 |
41A2303022N2B | 230×3.0×22.2 | 9×1/8×7/8 | 6600 | 80 | 25 | 50 |
